Max dia. swing over bed

mm

630

Max dia. swing over cross slide

mm

350

Max length of workpiece

mm

1500/2000/3000....

Width of bed

mm

550

Spindle bore

mm

104

Spindle nose

C11

Spindle taper hole

1:20/ 120

Power of spindle motor

Kw

11

Mode of spindle speed

Three gears   Smooth adjustment

Range of spindle speed

r/min

(L): 40-120  (M): 110-350  (H): 290-950

X/Z axis rapid traverse

mm/min

4000/ 8000

Min feeding set unit of X/Z axis

mm

0.001

X axis motor speed

r/min

1500

X axis motor torque

N.m

10

X axis motor power

Kw

1.5

Z axis motor speed

r/min

1500

Z axis motor torque

N.m

15

Z axis motor power

Kw

3.5

Tailstock quill diameter

mm

100

Tailstock quill travel

mm

250

Tailstock quill taper

MT6

Turret model

HAK-21240

Tool post type

Vertical 4- station

Turret dimension

mm

240x240

Turret indexing time

s

4.1

Chuck

K11-320   Three jaw chuck

Positioning accuracy

mm

0.02

Repositioning accuracy

mm

0.01

Machine size

mm

3700x1800x1800

Machine weight

Kg

5000
