Item | Unit | QK1313 |
Max dia. swing over bed | mm | 630 |
Max dia. swing over cross slide | mm | 330 |
Max length of workpiece | mm | 1500 |
Width of bed | mm | 550 |
Spindle bore | mm | 135 |
Power of spindle motor | Kw | 11 |
Mode of spindle speed | Two gears Smooth adjustment | |
Range of spindle speed | r/min | (L): 0-130 (H): 130-800 |
X/Z axis travel | mm | X:350 / Z:1250 |
X/Z axis rapid traverse | mm/min | 4000 |
X axis motor speed | r/min | 1500 |
X axis motor torque | N.m | 10 |
X axis motor power | Kw | 1.5 |
Z axis motor speed | r/min | 1500 |
Z axis motor torque | N.m | 15 |
Z axis motor power | Kw | 2.3 |
Tailstock quill diameter | mm | 100 |
Tailstock quill travel | mm | 250 |
Tailstock quill taper | MT5 | |
Turret model | HAK-21240 | |
Tool post type | Vertical 4- station | |
Turret dimension | mm | 240x240 |
Turret indexing time | s | 2.6 |
Chuck | K11-380 Three jaw chuck | |
Positioning accuracy | mm | 0.02 |
Repositioning accuracy | mm | 0.01 |
Machine size | mm | 3700x1755x1800 |
Machine weight | Kg | 4000 |
