Max dia. swing over bed

mm

1000

Max dia. swing over cross slide

mm

610

Max length of workpiece

mm

1500

Width of bed

mm

755

Spindle bore

mm

440

Power of spindle motor

Kw

22

Mode of spindle speed

Two gears  Smooth adjustment

Range of spindle speed

r/min

(L): 23-120  (H): 65-258

X/Z axis travel

mm

X:550 / Z:1250

X/Z axis rapid traverse

mm/min

4000

X axis motor speed

r/min

1500

X axis motor torque

N.m

18

X axis motor power

Kw

2.8

Z axis motor speed

r/min

1500

Z axis motor torque

N.m

22

Z axis motor power

Kw

3.5

Tailstock quill diameter

mm

140

Tailstock quill travel

mm

300

Tailstock quill taper

MT6

Turret model

SLD170A04N

Tool post type

Vertical 4- station

Turret dimension

mm

300x300

Turret indexing time

s

5.6

Chuck

K66-780  Four jaw chuck

Positioning accuracy

mm

0.02

Repositioning accuracy

mm

0.01

Machine size

mm

5000x2200x2100

Machine weight

Kg

14000
