Max dia. swing over bed

mm

1250

Max dia. swing over cross slide

mm

860

Max length of workpiece

mm

1500

Width of bed

mm

755

Spindle bore

mm

540

Power of spindle motor

Kw

22

Mode of spindle speed

Two gears Smooth adjustment

Range of spindle speed

r/min

(L): 23-120(H): 65-258

X/Z axis travel

mm

X:570 / Z: 1250

X/Z axis rapid traverse

mm/min

2000

X axis motor speed

r/min

2000

X axis motor torque

N.m

22

X axis motor power

Kw

2.8

Z axis motor speed

r/min

2000

Z axis motor torque

N.m

30

Z axis motor power

Kw

3.5

Tailstock quill diameter

mm

160

Tailstock quill travel

mm

300

Tailstock quill taper

MT6

Turret model

170A04N

Tool post type

Vertical 4- station

Turret dimension

mm

300x300

Turret indexing time

s

5.6

Chuck

Four jaw chuck

Positioning accuracy

mm

0.04

Repositioning accuracy

mm

0.02

Machine size

mm

5000x2800x2200

Machine weight

Kg

18000
